ZWO AM5N Harmonic Drive Equatorial Mount – Redefining Precision and Portability

The ZWO AM5N Harmonic Drive Equatorial Mount represents the pinnacle of modern astronomical technology. Designed for both visual observation and astrophotography, the AM5N combines advanced harmonic drive mechanics with a lightweight, compact design. Whether you're setting up in your backyard or traveling to a remote site, the AM5N offers reliability, precision, and unparalleled versatility.

Key Features:

1. Harmonic Drive Technology

   • Unlike traditional worm-gear systems, the harmonic drive mechanism ensures virtually zero backlash and offers exceptional tracking precision. This makes the AM5N ideal for long-exposure astrophotography, where smooth tracking is essential.

2. Equatorial and Alt-Az Modes

   • The AM5N operates in both equatorial and alt-azimuth configurations, providing flexibility for various applications. Beginners can enjoy intuitive alt-az tracking, while astrophotographers benefit from equatorial precision.

3. Lightweight and Portable

   • At just 5 kg (11 lbs), the AM5N is highly portable without sacrificing strength or stability. Its compact design is perfect for travel and on-the-go stargazing.

4. Impressive Payload Capacity

   • Despite its lightweight design, the mount supports a payload capacity of up to 13 kg (28.6 lbs) without a counterweight and 20 kg (44 lbs) with a counterweight, making it compatible with a wide range of telescopes and accessories.

5. Advanced Control Features

   • Compatible with the ZWO ASIAIR system for seamless control and integration.
   • Supports wireless and wired connections for remote operation.
   • Easy alignment process using a smartphone or tablet.

6. Precision Tracking and Slewing

   • Periodic Error: ±10 arcseconds (native), easily reduced with autoguiding.
   • Slewing Speed: 1.5°/sec, ensuring quick and smooth adjustments to celestial targets.

7. Silent Operation

   • The harmonic drive technology ensures near-silent operation, ideal for quiet environments.

8. Durable and Weather-Resistant

   • Built with high-quality materials, the AM5N is designed to endure a range of environmental conditions, ensuring long-term durability.

Specifications

• Mount Type: Harmonic Drive Equatorial/Alt-Az Mount
• Weight: 5 kg (11 lbs)
• Payload Capacity:
  • Without Counterweight: 13 kg (28.6 lbs)
  • With Counterweight: 20 kg (44 lbs)
• Drive Technology: Harmonic Drive
• Periodic Error: ±10 arcseconds (native)
• Slewing Speed: 1.5°/sec
• Alignment Methods:
  • Polar alignment scope (optional)
  • Smartphone/Tablet app-based alignment
• Connectivity:
  • USB, Wi-Fi, and Bluetooth
  • Compatible with ZWO ASIAIR and other third-party control software
• Power Requirements: 12V DC (via standard DC port)
• Power Consumption:
  • Standby: <0.5A
  • Slewing: ~3A
• Dimensions:
  • Compact and foldable for easy transport
• Operating Temperature: -10°C to 45°C (14°F to 113°F)
