Nyx, the deity of the night in ancient Greece, high-payload mount that can effortlessly support 20 kg of imaging equipment without requiring a counterweight or shaft.
Strain wave drive on the RA and DEC movements guarantees high torque and backlash-free operation at large payloads. An anodized black and blue aluminum alloy 6061 body that has been entirely CNC machined, along with a variety of branded components (stepper motors, strain wave gear) housed within the mount, guarantee that the Nyx-101 will operate without a hitch for many years. The RA axis of the mount is equipped with an electronic damper to prevent backsliding in the absence of power, in addition to safety limit stops during slew and tracking.
High precision strain wave gears
Harmonic Gears on Both Axis ensure high payload and a smooth, backlash-free operation.
A hybrid combination of a stepper motor & belt system along with sophisticated electronics can drive the RA axis down to 0.10 arcseconds of resolution
Supporting high imaging loads
Counterweights are not required for weights up to 20Kg.
(counterweights can be installed for higher photographic loads)
Lightweight Design
Lightweight Design, compared to the payload of weight the mount can lift
CNC-machined aluminum alloy AL6061 used for aircraft makes the mount an excellent choice for your setup.
Mount weights 6.4 Kg
From a small refractor to a fully loaded SCT 11-inch telescope, NYX-101 can easily handle the payload
Equatorial or Altazimuth Mode
Mount can be used as a German Equatorial mount or as an Altazimuth, more suitable for visual observations
The mode can be switched from our PC or Mobile Application
Built-in Wireless & USB Control
NYX-101 supports wireless and USB 2 connectivity out of the box.
Both technologies can work simultaneously.
Mount is compatible with LX200 protocol and Sky Safari for mobile interaction
Power Off Brake
A safety power-off brake is installed on the RA Axis and provides an instant safe stop
during a planned or unplanned power interruption.
Additional Key Features
DC 12 Volts Battery Operation
NYX-101 requires 12V only for its smooth operation. This means that you can use your normal 12V battery without any additional converters. Mount consumes less than 0.6Amp during tracking and up to 2.5 Amps during slewing.
Secure power and USB
The power cable is a GX12 type with can securely lock onto the mount. USB type B special socket ensures a secure grip. Both of these sockets are placed on the non-movable part of the mount. No cables moving during slews and tracking. A second GX12 socket allows you to provide power to your imaging equipment.
Refraction Corrections
NYX-101 integrates a barometric sensor required to calculate atmospheric refraction corrections during mount tracking. For smaller focal lengths this might be overkill but if you have an SCT you will notice a welcome change in your guiding performance.
Universal Saddle Plate
NYX-101 includes a low profile and rigid universal Saddle that accepts Vixen and Losmandy 3-ich dovetails.
Integrated ST-4 Autoguiding Port
An ST-4 port is available at the back of the mount. Port is compatible with a simple hand controller or with an ST-4 guiding camera.
REVIEW of Pegasus Astro NYX-101 Harmonic Gear Mount 👇
Polemaster Adapter
In the front of the mount, there is a place for the QHY Polemaster (adapter included), which allows you to perform a precise polar alignment, required for your imaging sessions.
Electronic assistant for initial polar alignment
A set of sensors allows you to orient the mount at the correct altitude and azimuth to have an initial, rough, polar alignment (for lower focal lengths such as camera lenses or visual observations ). Our mobile application guides you through that process.
Reverse Voltage Polarity Protection
NYX-101 has been designed with reverse voltage polarity protection. A saver if you accidentally reverse voltage or battery polarity during the night.
Optional Counterweight support
Mount does not require counterweights for payload up to 20Kg. However, if you would like to install counterweights for higher payloads there is a compatible M12 threaded shaft hole at the end of the DEC axis.
ASCOM, INDI, Sky Safari Support
The mount fully supports ASCOM 6 and INDI framework. Sky-Safari is also supported allowing you to control the mount through your mobile device.
LX200 Compatibility
LX200 protocol is fully compatible with NYX-101. Sky-Safari works out of the box with the mount.
Mobile Control
A mobile application for IOS and Android platforms allows you to control both axes of the mount, slew to installed catalogs of thousands of night sky targets and do a rough polar alignment through an electronic polar assistant.
Safety limits on RA axis
Safety limit encoders on RA Axis prevent internal cable snag or collision with the tripod.
Firmware Upgrade
An easy firmware upgrade process allows you to stay up to date with bug fixes and the latest features of the mount.
In the Box:
- NYX-101 Harmonic Geared Mount
- Power Supply 12V / 5A with GX12 jack
- Soft Case Carry Bag
- USB2 Type A to B Cable
- Azimuth Dowel
Mechanical Drawings
Technical Specification
| MATERIAL |
CNC MACHINED 6061 AIRCRAFT ALUMINUM ALLOY |
| Mount Mode |
Equatorial or Altazimuth |
| Mount Drive |
Strain Wave (Harmonic) Gear and Belt resulting reduction 500:1 (RA) and 300:1 (DEC) |
| Load Capacity |
20 Kg without counterweights
30 Kg with counterweights |
| Weight |
6.5 Kg |
| Safety / Power Off Brake |
On RA Axis |
| Dovetail |
Vixen and Losmandy 3-inch |
| RA Motor Resolution |
0.10” |
| Max Slew |
6 degs/sec |
| Power Voltage |
12V DC unregulated
0.7A during tracking, 2Amps during slewing |
| Guide Port |
ST4 |
| Counterweight Shaft |
M12 Shaft (1.75mm pitch) |
| Communication |
Wireless 802.11g and USB2 |
| Operating Temperature |
-20° to + 50°C |
| Warranty |
3 years |
| Made in (designed, assembled and tested) |
Greece. We carefully curate the entire manufacturing, testing and packing process. |
