A dedicated field flattener from William Optics designed specifically for the Z61 Apo telescope. Not compatible with the Star 61 guidescope. On the telescope side, this flattener features a male M54 thread for direct attachment to the focuser drawtube. To access the M54 female thread inside the drawtube, simply remove the 2" eyepiece holder ring. The camera side includes a male M48x0.75 thread, allowing you to connect a Canon, Nikon, or other DSLR using an M48-specific T-ring (sold separately). Note that it cannot be used with smaller 42 mm T-rings. This flattener does not include a standard 2" nosepiece or eyepiece holder-it is intended exclusively for direct camera connection to the William Optics Z61. A key convenience is the integrated rotator/camera angle adjuster, eliminating the need for a separate rotator. This is a true 1:1 flattener with no focal reduction. Zenithstar 61Compatibility:
Technical Specifications
Parameter
Value
Lens Design
2 Groups, 2 Elements
Telescope Connection
M54 x 0.75 (5mm thread depth)
Camera Connection
M48 x 0.75 (4mm thread depth)
Compatible Mounts
Canon EF / RF, Nikon F / Z, Sony E, Pentax K, Micro 4/3, FUJI X
Back Focus Requirement
67.7 mm
Adjustable Distance
12.9 mm
Image Circle
43 mm (Supports Full Frame Sensors)
Total Length
39.5 mm (Flattener) + 19 mm (Rotator/Adapter)
Weight
272.8 g (0.6 lbs)
