ZWO UV IR CUT filter - 2"

ZWO 2" UV/IR-Cut Filter – Sharper Imaging and H-Alpha Filter Protection

Product Description

Block Unwanted IR/UV Light & Capture Crystal Clear Astrophotography Images

The ZWO 2" UV/IR-Cut Filter is an essential addition to any astrophotography toolkit, especially for users of color CMOS and CCD cameras with AR-coated windows. This filter effectively blocks both ultraviolet (UV) and infrared (IR) light, preventing image degradation and protecting sensitive components like your H-alpha solar filters.

Most telescope optics are optimized for visible light, and infrared light—although invisible—can pass through and blur your astrophotography images. Additionally, IR and UV radiation can cause thermal damage to expensive solar filters. This is where the ZWO UV/IR filter proves its value.

Made from high-quality optical glass, this filter is mounted in a durable 2" metal cell. It provides excellent transmission in the visible spectrum while cutting off IR and UV beyond the useful imaging range.

Key Features

• Sharper Images: Blocks unfocused IR light, reducing halos and blurring around stars and deep-sky objects.

• Solar Filter Protection: Shields expensive H-alpha filters from harmful infrared and ultraviolet radiation.

• Precision Built: CNC-machined 2” cell with excellent internal light blocking and transmission quality.

• Prevents Thermal Damage: Protects filters and sensors from excessive heating caused by invisible IR/UV.

• Protective Case Included: Comes with a sturdy plastic case for safe storage.



Parameter	Value
Cell Diameter (D)	50.6 mm (1.99")
Total Filter Height (T)	7.5 mm (0.29")
Cell Height Excl. Threads (C)	5 mm (0.19")
Male Thread Length (M)	2.5 mm (0.09")
Female Thread	Not usable for stacking
Glass Thickness (S)	1.8 mm (0.07")
Clear Aperture (CA)	44 mm (1.73")
Thread Type	M48x0.75 Male
Weight	Lightweight, durable aluminum housing
