ZWO ASI585MC Planetary Camera

The ZWO ASI533MC is a cutting-edge camera specifically designed for astrophotography enthusiasts. It incorporates Sony's state-of-the-art IMX533 CMOS sensor, offering high sensitivity and low noise imaging, with back-illuminated technology that significantly enhances its performance in low-light conditions. This camera is well-suited for capturing the majesty of the night sky, from planets to galaxies, with exceptional detail and clarity.

Key Features:

• Sensor Type: Sony IMX533 CMOS, renowned for its stellar performance in astrophotography.
• Sensor Size: A 1-inch square sensor format with a resolution of 3008 x 3008 pixels, offering a broad field of view without compromising on detail.
• Pixel Size: The 3.76μm pixel size strikes an optimal balance between resolution and sensitivity.
• Analog-to-Digital Converter (ADC): With 14-bit ADC, it provides a wide dynamic range, capturing the faintest nuances of cosmic light.
• Read Noise: Exceptionally low read noise of 1.0e, ensuring cleaner image data and smoother gradients.
• Full Well Capacity: A substantial full well capacity of 50,000e, allowing for a wide range of brightness without saturation.
• Quantum Efficiency (QE): High QE of 80% for color sensors and up to 91% for monochrome, ensuring efficient photon collection for brighter images.
• Frame Rate: Capable of shooting up to 20 frames per second, which is ideal for stacking multiple exposures to increase image quality.

Advanced Imaging Capabilities:

• STARVIS Technology: The ASI533MC utilizes Sony's STARVIS technology, optimized for impressive performance in low-light conditions, which is crucial for night sky observations.
• Protective Window: The sensor is safeguarded by a 2mm-thick AR-coated protective window that not only prevents dust and other particles from affecting the sensor but also maximizes light transmission.

REVIEW of ZWO ASI585MC Planetary Camera 👇

Design and Construction:

• Cooling System: The camera employs a passive cooling system, making it robust and low-maintenance.
• Protect Window: Includes an anti-reflective coated window for maximum light gathering without spectral interference.
• Body: Features a compact and durable design with a signature red metallic finish that's characteristic of ZWO products.

Connectivity and Integration:

• USB 3.0 Interface: For fast and efficient data transfer, a necessary feature for high-resolution astrophotography.
• Autoguider Port: The inclusion of an ST4 autoguider port allows for precise tracking control during long-exposure imaging sessions.

In the Box:

• ZWO ASI533MC Camera Unit: The core of your astrophotography setup.
• 1.25" and 2" Covers: To protect your sensor from environmental contaminants.
• ST4 Cable: For connecting to autoguider equipment for tracking.
• USB 3.0 Cable: A 2-meter long cable to connect the camera to your computer. (Note: the color of the USB cable was changed from black to red since June 2023.)
• 1.25" Nosepiece: For attaching the camera to various telescope configurations.
• Quick Start Guide: To assist with a quick and easy setup process.
