D78 Holder Ring

Currently compatible with the following ZWO cameras: ASI1600 Pro, ASI183 Pro , ASI294 Pro, ASI533 Pro, ASI178 Cooled cameras, ASI174 Cooled cameras and ASI385MC cooled cameras.

NOTICE: ASI094, ASI128 & ASI071 Pro cameras require 86mm holder ring.

To easily mount the camera onto the tripod, simply loosen the M6 screw on the side of the holder ring. Done!

Mechanical Diagram

D86 Holder Ring

ZWO Holder Ring for ZWO ASI PRO COOLED CAMERAS with appr 86mm diameter.

Currently compatible with the following ZWO cameras: ASI094, ASI128 and ASI071 Pro cameras ; )

To easily mount the camera onto the tripod, simply loosen the M6 screw on the side of the holder ring. Done!

Mechanical Diagram

D90 Holder Ring

Product : 90mm diameter

Currently compatible with ASI 2600MM/MC Pro and ASI6200MM/MC Pro cameras.

Note:

1. Cameras with large format like ASI094MC Pro, ASI128MC Pro and ASI071MC Pro require the D86 Holder Ring (80mm diameter).

2. D78 Holder Ring for ASI Cooled cameras is compatible with following ZWO cameras:

ASI1600 Pro cameras, ASI183 Pro cameras, ASI294MC Pro, ASI178 Cooled cameras, ASI174 Cooled cameras and ASI385MC cooled.

3. To easily mount the camera onto the tripod, simply loosen the M6 screw on the holder ring. Done!

Mechanical Diagram
